LD Systems STINGER G3 - 12 Passive 8" 2-Way PA Speaker

Loading product options

This highly professional 2-way loudspeaker is designed for absolute, long-term reliability. With its multifunctional bass reflex cabinet as a full range speaker, satellite and ground monitor, it is suited to mobile and fixed PA systems.

The STINGER® 12 G3 provides 400 watts of continuous power; the maximum sound pressure level is 125 dB. Its specially developed 12" woofer and the BMS HF driver achieve a powerful bass reproduction and fresh natural highs. The wave guide of the tweeter has been developed using the Boundary Element Method (BEM), a numerical simulation of the sound radiation and dispersion. It reduces reflections from the floor and ceiling and prevents sidelobe levels and thus achieves a controlled and homogeneous dispersion.

The STINGER® 12 G3 is designed as a real all-round workhorse. The cabinet is made from robust birch plywood and offers an exceptional stability and durability thanks to its extremely durable polyurea coating.

The features include a steel grille, a Dual-Tilt stand attachment, flight points and ergonomic handles. The STINGER® 12 G3 is an affordable solution for professional PA applications; extensive accessories support use on stage and in fixed installations.

Features
  • 2-way passive 12” bass reflex PA speaker
  • 400 watts RMS power handling
  • 125 dB maximum SPL
  • 12“ custom woofer and BMS compression driver
  • BEM optimised HF waveguide for uniform coverage
  • Birch ply cabinet with ultra rugged polyurea finish and M10 suspension points
  • Shock-resistant front grill provides maximum speaker protection
  • 36 mm Dual-Tilt pole receptacle for 0° or 5° mounting angles
  • Large selection of smart installation and transport accessories
  • Product type: PA loudspeaker
  • Type: Passive
  • Dispersion (H x V): 90 x 50 °
  • Load rating (RMS): 400 W
  • Peak power: 800 W
  • Frequency response: 58 - 20000 Hz
  • SPL (1W/1m): 99 dB
  • Max. SPL: 125 dB
  • Impedance: 8 Ohm(s)
  • Loudspeaker inputs: 1
  • Speaker input connections: Speakon compatible
  • Loudspeaker outputs: 1
  • Speaker output connections: Speakon compatible
  • Speakers per amplifier channel (DSP44/45K): 3
  • Monitor angle: 54 °
  • Width: 390 mm
  • Height: 627 mm
  • Depth: 377 mm
  • Weight: 19.4 kg
